Video Compression H.265 Pro+/H.265 Pro/H.265/H .264+/H.264

Coding Resolution when 1080p Lite mode is not activated: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF

When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF

Frame rate Main stream: When 1080p Lite mode is not activated: For 4 MP stream access: 4 MP lite@15fps

1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP streaming access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p streaming access: 1080p/720p@15fps

VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p streaming access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode is enabled: 4 MP lite/3 MP@15fps

1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Substream: WD1/4CIF@12fps

CIF@25fps (P)/30fps (N)

Video Bitrate 32 Kbps - 6 Mbps

Dual Flow Support

Stream Type Video, Video and Audio

Audio Compression G.711u

Audio Bitrate 64 Kbps

Video & Audio

IP Video Input 2-channel (up to 10 channels) Enhanced IP mode on: 4-ch (up to 12-ch), resolution up to 6 MP each up to 4 Mbps H.265+/H .265/H.264+/H .264 Supports IP cameras

Incoming Bandwidth 48 Mbps

Analog Video Input 8 channel BNC interface (1.0 Vp-p, 75 ?), supports coaxitron connection

HDTVI Input 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 *: 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1.

AHD Input 4 MP, 1080p25, 1080p30, 720p25, 720p30

HDCVI Input 4 MP, 1080p25, 1080p30, 720p25, 720p30

CVBS Input Support

VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Audio input 1-ch, RCA (2.0 Vp-p, 1 K?) 8-channel coaxial cable

Audio Output 1-ch, RCA (Linear, 1 K?)

Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 K?) (using first audio input)

Simultaneous Playback 8-channel

net

Total Bandwidth 96 Mbps

Remote Connection 64

Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTP, ONVIF

Network Interface 1, RJ45 10M/100M self-adaptive Ethernet interface

Auxiliary Interface

SATA 1 SATA interface

Capacity Up to 6TB capacity per disc

No Alarm Input/Output

USB Interface Actual panel: 2 × USB 2.0

General

Power Supply 12 VDC, 1.33 A

Consumption ? 12W

Operating Temperature -10°C to +55°C (+14°F to +131°F)

Operating Humidity 10% - 90%

Dimension (W × D × H) 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inches)

? 1 kg (2.2 lb)
